Optimizing ClickHouse Join Performance

ClickHouse is an amazing database engine. Want to handle billions of rows of data? Want your queries to return in milliseconds? Want to do both of those while still using SQL instead of some one-off query language or API? ClickHouse ticks all of those boxes. For developers coming to ClickHouse from more traditional OLTP databases like Postgres, MySQL or SQL Server it immediately feels familiar and powerful. But a quick dive into the excellent documentation makes clear that there are some key differences that developers and users need to understand in order get the best out of it.

The most significant differences between ClickHouse and the more familiar OLTP databases arise from the way that data is stored as well as the algorithms that are used to find matching records. An essential first step for new users is to understand the importance of designing schema with well thought out primary keys and compression for the fields in each table. With just these few new concepts in hand it's easy to start building systems that handle huge data loads with shockingly fast response times. Unfortunately, the familiar SQL interface to this tool can draw an unsuspecting user into a performance trap that can cause queries to run far slower than they should.

The culprit here, as I'm sure you'll have deduced from the title, is the JOIN operation. This essential component of SQL needs to be handled carefully in ClickHouse so that it won't explode execution times and memory usage. This isn't to say that you shouldn't use joins. After all, a database with no joins isn't very relational. Instead, you should apply what you know about your data to carefully construct those relations in a way that works well with ClickHouse's execution model.

A Relationship We All Know

Let's start by constructing a simple schema that we can use to explore how problems can arise when joining tables in a query. We'll consider a parent/child relationship with UInt64 ID fields that we will populate with a snowflake ID which will provide the link between child and parent:

1CREATE TABLE example.parent
2(
3    `id` UInt64 CODEC (Delta, ZSTD), -- Snowflake ID
4    `tags` Array(String), -- Denormalized metadata about parent
5    -- ... Other fields can exist in columnar DB with no impact on query at hand
6)
7ENGINE = MergeTree
8ORDER BY id;

1CREATE TABLE example.child
2(
3    `id` UInt64 CODEC (Delta, ZSTD), -- Snowflake ID
4    `parent` UInt64, -- Reference to parent.id
5    `tags` Array(String), -- Denormalized metadata about this child entity
6    -- ... Other fields can exist in columnar DB with no impact on query at hand
7)
8ENGINE = MergeTree
9ORDER BY id;

The primary key/order by for each of these tables is the aforementioned snowflake ID for each respective entity, implying that both parent and child are time-series in some fashion. This sort of schema arises in many situations like tracing, event monitoring or even the original use case for snowflake, Twitter's post and comment identifiers. For those unfamiliar with snowflake IDs, one of the big draws is that they are sortable by time such that a snowflake generated for a later date will have a greater value than one generated for an earlier date.

Both the parent and child records have a field called tags which is an array of strings representing some sort of denormalized metadata that we want to search on. We also assume that each of these tables would have additional columns, but those will make no difference to the queries that we'll look at since ClickHouse is a columnar database.

Let's start off by creating some random data that we can test against. The following script will generate a million parent records and a hundred million child records, which will be randomly distributed among the parents. Child records have an ID based on a timestamp between the parent's value and one week after. Additionally, each record, whether child or parent has a tags array with zero to ten strings that range in length from zero to three characters.

 1SET param_BASE = 1000000; -- BASE determines the number of parent records that will be created
 2SET param_RATIO = 100; -- RATIO determines how many child records will be created with respect to the number of parent records created
 3SET param_MILLIDAY = 86400000; -- Milliseconds in a day
 4
 5WITH parent_vals AS (
 6  -- Create records from now back through one year prior
 7  SELECT (now() - toIntervalMillisecond(randUniform(0, {MILLIDAY:UInt64} * 365))) AS ts, tags
 8  FROM generateRandom('tags Array(String)', NULL, 3, 10)
 9  LIMIT {BASE:UInt64}
10)
11INSERT INTO example.parent
12SELECT
13  dateTime64ToSnowflakeID(parent_vals.ts) AS id,
14  parent_vals.tags AS tags
15FROM parent_vals;
16
17WITH parent_vals AS (
18  SELECT row_number() OVER () AS p_row,
19    id AS parent,
20    snowflakeIDToDateTime(id) AS ts
21  FROM example.parent
22),
23child_vals AS (
24  -- Create child records from parent time up through a week later
25  SELECT toIntervalMillisecond(randUniform(0, {MILLIDAY:UInt64} * 7)) AS ts_offset,
26    -- Find random parent for each child row created by referencing row_number from above
27    (rand64() % {BASE:UInt64} + 1) AS p_row,
28    tags
29  FROM generateRandom('tags Array(String)', NULL, 3, 10)
30  LIMIT ({BASE:UInt64} * {RATIO:UInt64})
31)
32INSERT INTO example.child
33SELECT dateTime64ToSnowflakeID(parent_vals.ts + child_vals.ts_offset) AS id,
34  parent_vals.parent AS parent,
35  child_vals.tags AS tags
36FROM child_vals
37INNER JOIN parent_vals ON parent_vals.p_row = child_vals.p_row;

This whole dataset takes up about 2.2 GB of disk space and on my MacBook Pro it takes about 30 seconds to run.

A Simple Question

Let's start off with a straightforward query. We want to find all of the child entities which have a parent entity with a particular tag, and we want to return the arrays of tags for those child entities. Keeping in mind that the data in question is randomly generated, let's verify that there's at least one matching parent for a given tag, 'aaa':

 1SELECT count()
 2FROM example.parent
 3WHERE has(parent.tags, 'aaa');
 4
 5   ┌─count()─┐
 61. │       3 │
 7   └─────────┘
 8
 91 row in set. Elapsed: 0.093 sec. Processed 1.00 million rows, 60.52 MB (10.71 million rows/s., 647.94 MB/s.)
10Peak memory usage: 21.75 MiB.

Okay, looks like we're good. This dataset has the tag 'aaa' present in three parent records. And finding those parent records is fast, taking only 93 milliseconds and 21.75 MiB of memory despite a lack of any indexing on the column. Finding the related child records is a simple matter of joining the child table:

 1SELECT child.tags
 2FROM example.parent
 3INNER JOIN example.child ON parent.id = child.parent
 4WHERE has(parent.tags, 'aaa');
 5
 6     ┌─child.tags───────────────────────────────────────────────┐
 7  1. │ []                                                       │
 8  2. │ [',g','x`','7h','QD-','k.~','}_']                        │
 9  ...
10308. │ ['','N`',',r\\']                                         │
11309. │ ['',':9k','','X)h','#EY','w<']                           │
12     └─child.tags───────────────────────────────────────────────┘
13
14309 rows in set. Elapsed: 3.663 sec. Processed 101.00 million rows, 6.85 GB (27.31 million rows/s., 1.87 GB/s.)
15Peak memory usage: 7.79 GiB.

This query gives us our answer and it took about 40 times longer to execute than the previous select that only involved the parent, but considering the child table has 100x more rows, that might not seem unreasonable. But that memory usage should stand out as a big warning sign. We used over 7 GiB for this new query.

Left and Right - Not Just for Driving Directions

What's going on here to cause the memory consumption to go up so much? In the ClickHouse using JOINS guide the second bullet point on the page lays it out:

• Currently, ClickHouse does not reorder joins. Always ensure the smallest table is on the right-hand side of the Join. This will be held in memory for most join algorithms and will ensure the lowest memory overhead for the query.

Looking at our use case, the child table has 100x more rows than the parent table and we are using that child table on the right side of our join. Let's see what happens if we switch the order of these two tables in the query.

1SELECT child.tags
2FROM example.child
3INNER JOIN example.parent ON parent.id = child.parent
4WHERE has(parent.tags, 'aaa');
5
6-- Results snipped out for brevity
7
8309 rows in set. Elapsed: 1.556 sec. Processed 101.00 million rows, 6.91 GB (64.90 million rows/s., 4.44 GB/s.)
9Peak memory usage: 159.67 MiB.

Switching around the join order of this query makes an enormous difference. The execution time improved by a factor of 2.3 and the memory consumption improved by a factor of 48. ClickHouse isn't the only database for which join order can be important, but many of us are used to relying on the optimizer reordering joins in other DB engines. Many other RDBMS systems generate statistics about data distribution in every table and column so that the optimizer can make informed decisions about how to restructure queries for optimal performance. For the time being, the best optimizer for your ClickHouse queries will be you and your understanding of the data.

Being More Explicit - SEMI JOIN

Since we are now relying on our own knowledge of the data and the intentions of the query, perhaps we should consider a join type that more explicitly conveys why we are using a join in the first place. INNER JOIN implies that we intend to return columns from both the left and right side of the join, but in our case the parent table is simply used as a filter for values in the child table. This is exactly the domain of the SEMI JOIN. Let's try out a SEMI LEFT JOIN and see how that affects performance.

1SELECT child.tags
2FROM example.child
3SEMI LEFT JOIN example.parent ON parent.id = child.parent
4WHERE has(parent.tags, 'aaa');
5
6-- Results snipped out for brevity
7
8309 rows in set. Elapsed: 2.949 sec. Processed 101.00 million rows, 6.92 GB (34.24 million rows/s., 2.35 GB/s.)
9Peak memory usage: 198.49 MiB.

Looking at the results, we actually ended up with 1.9 times worse execution time and slightly worse memory usage than our INNER JOIN version above. How is that? I can't say for certain, but I suspect that there has been at least one optimization that ClickHouse has implemented for INNER JOIN which has not made it into the SEMI LEFT JOIN, and that optimization is to push down aspects of the WHERE clause into the ON clause for the join criteria. Let's see what happens if we explicitly make the check for the parent tags part of the ON clause.

1SELECT child.tags
2FROM example.child
3SEMI LEFT JOIN example.parent ON (parent.id = child.parent) AND has(parent.tags, 'aaa');
4
5-- Results snipped out for brevity
6
7309 rows in set. Elapsed: 1.529 sec. Processed 101.00 million rows, 6.92 GB (66.05 million rows/s., 4.52 GB/s.)
8Peak memory usage: 88.75 MiB.

Moving the tags check into the ON clause seems to have done the trick and the INNER and SEMI LEFT joins now perform very similarly in terms of both execution time as well as memory usage. But what is actually happening to yield the improvements in both execution time and memory consumption? As stated above, the right hand table of a join will be held in memory for the entire join operation. The more filtering that we can achieve in the ON clause, the smaller that right table will be, reducing memory consumption, but also improving execution time because there are fewer records to compare against the left hand side.

Unfortunately, we are just at parity with the assumedly optimized INNER JOIN rather than achieving better performance. Is this the best that we can do?

A JOIN By Any Other Name

Fortunately we can achieve JOIN behavior in other ways that might help us out further. Since our query is logically a LEFT SEMI JOIN with only a single join key, that means it is equivalent to selecting records in child where parent is in a list of parent.id values that we can find with a sub-query.

 1SELECT child.tags
 2FROM example.child
 3WHERE parent IN (
 4    SELECT id
 5    FROM example.parent
 6    WHERE has(parent.tags, 'aaa')
 7);
 8
 9-- Results snipped out for brevity
10
11309 rows in set. Elapsed: 0.148 sec. Processed 101.00 million rows, 926.96 MB (684.36 million rows/s., 6.28 GB/s.)
12Peak memory usage: 29.64 MiB.

Wow, that's much better! The execution time is 10.5 times better and memory usage has gone down by a factor of 5.4 compared to the INNER JOIN that had parent as the right table. Compared to our original INNER JOIN with the child table on the right we have reduced execution time by a factor of 24.8 and memory usage by a factor of 263. All of this was done without modifying our schema and without adding any sort of projections or indexes.

A Slightly Less Simple Question

What if we actually need the added features of a join and want to return data from more than one table? Let's reformulate our original goal and say that we still want to find all of the tags for each child record, but we also want the full set of tags for the parent where that parent has a 'aaa' tag present. That's as easy as adding parent.tags to our INNER JOIN.

1SELECT parent.tags AS parent_tags, child.tags AS child_tags
2FROM example.child
3INNER JOIN example.parent ON parent.id = child.parent AND has(parent.tags, 'aaa');
4
5-- Results snipped out for brevity
6
7309 rows in set. Elapsed: 1.489 sec. Processed 101.00 million rows, 6.92 GB (67.83 million rows/s., 4.65 GB/s.)
8Peak memory usage: 162.55 MiB.

Impressively, ClickHouse is actually returning this larger set of data slightly faster than the simpler query, but likely below the noise threshold. Similarly, the memory usage has remained nearly the same as well. Given what we already know about improving the performance of the simpler query, can we improve this INNER JOIN? Knowing that the key to performance is reducing the size of the tables in the join, let's try to limit just the parent set.

 1SELECT parent_sub.tags as parent_tags, child.tags as child_tags
 2FROM example.child
 3INNER JOIN (
 4  SELECT id, tags
 5  FROM example.parent
 6  WHERE has(parent.tags, 'aaa')
 7) AS parent_sub ON child.parent = parent_sub.id;
 8
 9-- Results snipped out for brevity
10
11309 rows in set. Elapsed: 1.561 sec. Processed 101.00 million rows, 6.92 GB (64.70 million rows/s., 4.43 GB/s.)
12Peak memory usage: 164.38 MiB.

That looks like a wash. We don't see any improvement over the straightforward INNER JOIN that we started with. What about optimizing the left side of the join by reducing the size of that table too?

 1SELECT parent_sub.tags, child_sub.tags
 2FROM (
 3  SELECT child.parent, child.tags
 4  FROM example.child
 5  WHERE parent IN (
 6    SELECT id
 7    FROM example.parent
 8    WHERE has(parent.tags, 'aaa')
 9  )
10) AS child_sub
11INNER JOIN (
12  SELECT id, tags
13  FROM example.parent
14  WHERE has(parent.tags, 'aaa')
15) AS parent_sub ON child_sub.parent = parent_sub.id;
16
17-- Results snipped out for brevity
18
19309 rows in set. Elapsed: 0.159 sec. Processed 102.00 million rows, 1.02 GB (640.01 million rows/s., 6.39 GB/s.)
20Peak memory usage: 54.34 MiB.

That seems to have done it. We are now getting comparable performance for this inner join as we got with our IN clause in the simpler use case. The path to this was thinking about how we can minimize the size of data at each step in the query.

That's Great, But Could You Make It Less Ugly?

Our new query is certainly more performant, but it isn't without tradeoffs from a software engineering perspective. This approach is far less readable than the simple INNER JOIN was and it also suffers from repetition in a way that could easily lead to future bugs if only one of the parent subqueries got updated with new requirements, like adding in a date range to the where clause (using a nice feature of snowflake IDs).

How can we make this new query more understandable while retaining the performance benefits that got us here? The answer is to use the Common Table Expression, or CTE. CTEs allow the programmer to specify named subqueries using the WITH clause and then refer to them later in the query. For our purposes we will create two CTEs.

 1WITH parent_matches AS (
 2  SELECT parent.id AS parent_id, parent.tags AS parent_tags
 3  FROM example.parent
 4  WHERE has(parent.tags, 'aaa')
 5),
 6child_matches AS (
 7  SELECT child.parent AS parent_id, child.tags AS child_tags
 8  FROM example.child
 9  WHERE child.parent IN (
10    SELECT parent_id
11    FROM parent_matches
12  )
13)
14SELECT parent_tags, child_tags
15FROM child_matches
16INNER JOIN parent_matches USING parent_id;
17
18-- Results snipped out for brevity
19
20309 rows in set. Elapsed: 0.144 sec. Processed 102.00 million rows, 967.24 MB (708.30 million rows/s., 6.72 GB/s.)
21Peak memory usage: 54.35 MiB.

The use of common table expressions has allowed us to centralize the rule that parent.tags has to have a value of 'aaa'. No more duplication of the filtering portion of the query. Well written CTEs can also convey intention to other developers in a way that deeply nested subqueries often obscure.

CTEs - Building Blocks for Optimization Fences

ClickHouse handles common table expressions the same way that it does subqueries. That is to say, it simply replaces a CTE in your query with the corresponding query that was specified. And how does ClickHouse handle subqueries? Right now it does so in the most straightforward manner, executing the contained query and utilizing the result as a sort of virtual table.

The optimizer will not attempt to rewrite a subquery with knowledge from the containing query. It will not push down expressions from a parent WHERE clause into the subquery nor any other advanced techniques. Because of this, subqueries and CTEs are often referred to as optimization fences, meaning that the database engine will not optimize across the boundary. This isn't the case for all database systems and some even have complex rules around when a CTE boundary is an optimization fence. Postgres, for instance, supports the syntax MATERIALIZED and NOT MATERIALIZED in order to specify whether a CTE should be an optimization fence or not, allowing the user to escape the complex rules and use their own understanding of the data to provide the best query.

Knowing that we have this tool available to us in ClickHouse provides developers with an opportunity to construct complex queries from simpler building blocks that are each optimized for their particular need. Simple, well-composed systems are easier to reason about and help to reduce maintenance costs. These simpler components also help us to achieve a goal that often gets overlooked when we optimize: consistency. A query that executes very fast most of the time, but which has very poor P99 values is going to cause big headaches. Comprehensible CTEs allow us to reason about what conditions can lead to outliers.

If you find yourself in a situation where you have to utilize joins in your query it's a pretty good idea to start off constructing CTEs that express your intent. As your query grows more complex it will be even more important.

Be Wary of JOINs Below the Surface - Denormalization with Materialized Views

One of the best pieces of advice for consistently achieving optimal performance in ClickHouse as well as any other RDBMS is to eliminate joins entirely where possible. The most prominent way to avoid joins in user-facing code is to denormalize your data such that disparate fields from multiple tables are brought together into a single table that is optimized for the queries that are performance-sensitive. ClickHouse provides an easy path for this approach with an array of options for materialized views, including incremental materialized views that can continuously build out denormalized tables as new records are inserted into the constituent tables. User-facing queries are then run against this denormalized data in such a way that joins are not needed, or are at least minimized.

It's important to realize, though, that we haven't removed joins from our workflow, we've just moved them to another part of the data path. When we write the query for the materialized view the join will be run in the background when new source records are inserted. Depending on how these inserts are performed, ClickHouse may perform all of the materialization prior to returning from an insert.

What happens if joins present in incremental materialized views start blowing up as data volumes increase? What if these joins exceed the allowed memory usage per query? The answer is that inserts will start to either fall behind or fail entirely. For many systems this is a far worse situation than poor performance for end-user queries. Losing any input data can be catastrophic in some systems. Worse, the warning signs for poor insert performance are often harder to spot than similar problems for those querying the data.

Optimizing your joins in materialized views is at least as important as doing so in your user-facing queries. Fortunately, the techniques laid out above apply to incremental materialization in the exact same ways. The one caveat that I would give is that you should weigh the relative importance of execution time and memory usage slightly differently for an incremental materialization query compared with a user-facing query. Keeping peak memory usage low is critical for materialization because that will help to insure that inserts don't fail, even if they are slightly slower. Fortunately, even if you are dealing with very large datasets there are ways to constrain memory usage beyond just query structure. ClickHouse gives you the ability to specify the join algorithm that will be used and some of these will prevent excessive memory consumption as you grow into billions of rows of data. But that's a whole new topic that deserves a post all to itself.
